Gazelle Arroyo C5 Elite
Gazelle Arroyo C5 Elite
The Full Scoop on the Gazelle Arroyo C5
The Gazelle Arroyo C5 Elite offers iconic Dutch style with sleek accessories and comfort-optimized components. A roomy step-through frame welcomes steady and refined riding for city trips and beyond.
A mid-mounted Bosch Smart System motor provides up to 75 Nm of torque and while an integrated 500 Wh in-tube battery enables a low center of gravity and distinctly smooth ride feel in an elegant and classic silhouette.
The Gazelle Arroyo C5 offers a relaxed riding in a comfortable upright position with the power to go beyond commutes around town. Tap into the spirit of classic Dutch bikes for the 21st century thanks to robust assistance and modern components.
*Components subject to manufacture changes.
| Motor | Bosch performance Line, Smart System (75Nm) |
| Battery | Bosch 500Wh,Integrated into frame |
| Display | Bosch Intuvia 100 |
| Charger | 4Ah |
| Frame | Stable, lightweight hydro-formed aluminum frame with 68.5° headset angle and 69.5° saddle tube angle for relaxed and comfortable riding. This is a low-step and spacious frame, single tube and lovely integrated cables. |
| Fork | Aluminum. springing in headset, 40mm |
| Rear Shock | Not applicable |
| Front Brake | Tektro HD-T280 hydraulic disc brakes, 2 piston, 180mm |
| Rear Brake | Tektro HD-T280 hydraulic disc brakes, 2 piston, 160mm |
| Drivetrain / Rear Derailleur | Belt |
| Shift Levers | Shimano Nexus 5 |
| Chain | Gates CDX belt drive, with Centertrack |
| Cassette | Spec not provided |
| Crankset | Spec not provided |
| Chain Ring | Front chainwheel 46 / Rear chainwheel 34 |
| Chain Guard | Aluminum |
| Rims | RODI Viper |
| Front Hub | Shimano |
| Rear Hub | Shimano Nexus, 5 speeds, hub brake |
| Front Tire | Schwalbe Energizer Active Plus, 47-622 |
| Rear Tire | Schwalbe Energizer Active Plus, 47-622 |
| Handlebar | Aluminum, comfort curved model |
| Stem | Steeplessly adjustable |
| Headset | Spec not provided |
| Grips | Gazelle Aero leather |
| Saddle | Selle Royal Essenza Plus |
| Seatpost | Sprung |
| Pedals | Spec not provided |
| Front Light | Gazelle Fendervision, LED headlamp, on/off switching via display |
| Rear Light | Spanninga Brasa, LED battery supply, on/off switching via display |
| Kickstand | Drop-down rear stand, Ursus Mooi |
| Rear Carrier | Aluminum MIK HD system carrier |
| Fenders | Spec not provided |
| Bell | Spec not provided |
| Lock | AXA Defender. Ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft |
| Mirror | Not applicable |
The Full Scoop on the Gazelle Arroyo C5
The Gazelle Arroyo C5 Elite offers iconic Dutch style with sleek accessories and comfort-optimized components. A roomy step-through frame welcomes steady and refined riding for city trips and beyond.
A mid-mounted Bosch Smart System motor provides up to 75 Nm of torque and while an integrated 500 Wh in-tube battery enables a low center of gravity and distinctly smooth ride feel in an elegant and classic silhouette.
The Gazelle Arroyo C5 offers a relaxed riding in a comfortable upright position with the power to go beyond commutes around town. Tap into the spirit of classic Dutch bikes for the 21st century thanks to robust assistance and modern components.
*Components subject to manufacture changes.
Motor System
| Motor | Bosch performance Line, Smart System (75Nm) |
| Battery | Bosch 500Wh,Integrated into frame |
| Display | Bosch Intuvia 100 |
| Charger | 4Ah |
Components
| Frame | Stable, lightweight hydro-formed aluminum frame with 68.5° headset angle and 69.5° saddle tube angle for relaxed and comfortable riding. This is a low-step and spacious frame, single tube and lovely integrated cables. |
| Fork | Aluminum. springing in headset, 40mm |
| Rear Shock | Not applicable |
| Front Brake | Tektro HD-T280 hydraulic disc brakes, 2 piston, 180mm |
| Rear Brake | Tektro HD-T280 hydraulic disc brakes, 2 piston, 160mm |
| Drivetrain / Rear Derailleur | Belt |
| Shift Levers | Shimano Nexus 5 |
| Chain | Gates CDX belt drive, with Centertrack |
| Cassette | Spec not provided |
| Crankset | Spec not provided |
| Chain Ring | Front chainwheel 46 / Rear chainwheel 34 |
| Chain Guard | Aluminum |
| Rims | RODI Viper |
| Front Hub | Shimano |
| Rear Hub | Shimano Nexus, 5 speeds, hub brake |
| Front Tire | Schwalbe Energizer Active Plus, 47-622 |
| Rear Tire | Schwalbe Energizer Active Plus, 47-622 |
| Handlebar | Aluminum, comfort curved model |
| Stem | Steeplessly adjustable |
| Headset | Spec not provided |
| Grips | Gazelle Aero leather |
| Saddle | Selle Royal Essenza Plus |
| Seatpost | Sprung |
Extras
| Pedals | Spec not provided |
| Front Light | Gazelle Fendervision, LED headlamp, on/off switching via display |
| Rear Light | Spanninga Brasa, LED battery supply, on/off switching via display |
| Kickstand | Drop-down rear stand, Ursus Mooi |
| Rear Carrier | Aluminum MIK HD system carrier |
| Fenders | Spec not provided |
| Bell | Spec not provided |
| Lock | AXA Defender. Ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft |
| Mirror | Not applicable |
