Orbea Rise LT M10
Orbea Rise LT M10
Regular price
$8,999.00
Sale price
$8,999.00
Regular price
Unit price
per
Couldn't load pickup availability
The Full Scoop on the Orbea Rise LT M10
*Components subject to manufacturer changes
The Orbea Rise LT just might be one of the best eMTB's we've come across. The Rise stands out with an incredible build, value, power all in one of the lightest eMTB's available!  We've become huge fans of the Orbea Rise LT as it's one of the most nimble electric mountain bikes we've ridden.Â
*Components subject to manufacturer changes
| Motor | Shimano EP801 |
| Battery | Orbea Internal 420Wh / 630Wh |
| Display/Remote | EN600-L |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
| Frame | Orbea Rise OMR 2025, 140mm travel, 29" wheels, Concentric Boost 12x148 |
| Fork | Fox 36 Float Factory 160 Grip X QR15x110 Kashima |
| Rear Shock | Fox Float X Factory 2-Pos Adjust Evol LV Kashima custom tune 210x55mm |
| Front Brake | Shimano XT M8120 Hydraulic Disc |
| Rear Brake | Shimano XT M8120 Hydraulic Disc |
| Rear Derailleur | Shimano XT M8100 SGS Shadow Plus |
| Shift Levers | Shimano SLX M7100 I-Spec EV |
| Chain | Shimano M7100 |
| Cassette | Shimano CS-M7100 10-51t 12-Speed |
| Crankset | Shimano Steps EM600 |
| Chain Ring | Spec not provided |
| Chain Guard | Orbea Rise chainguide |
| Rims | Oquo Mountain Control MC32TEAM, alloy hookless rim, DT350 6IS hub, 32mm internal width, Sapim D-Sprint / Race spokes, 29" |
| Front Hub | Spec not provided |
| Rear Hub | Spec not provided |
| Front Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Rear Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Handlebar | OC Mountain Control MC10 Carbon, Rise 20, Width 800 |
| Stem | OC Mountain Control MC20, 0º |
| Headset | Alloy 1-1/2", Black Oxidated Bearing |
| Grips | Ergon GE10 |
| Saddle | Fizik Terra Ridon X5 145mm |
| Seatpost | OC MC21 Mountain Control Dropper, 31.6mm |
| Pedals | Not applicable |
| Front Light | Not applicable |
| Rear Light | Not applicable |
| Kickstand | Not applicable |
| Rear Carrier | Not applicable |
| Fenders | Not applicable |
| Bell | Not applicable |
| Lock | Not applicable |
| Mirror | Not applicable |
| FRAME SIZE | S | M | L | XL |
|---|---|---|---|---|
| Seattube length | 380mm | 420mm | 450mm | 490mm |
| Toptube length | 605mm | 625mm | 650mm | 670mm |
| Bottom bracket drop | -25mm | -25mm | -25mm | -25mm |
| Bottom bracket height | 350mm | 350mm | 350mm | 350mm |
| Chainstay length | 455mm | 455mm | 455mm | 455mm |
| Seat tube angle | 73.5° | 73.5° | 73.5° | 73.5° |
| Effective seattube angle | 77° | 77° | 77° | 77° |
| Headtube angle | 66° | 66° | 66° | 66° |
| Fork Offset | mm | mm | mm | mm |
| Wheelbase | 1180mm | 1205mm | 1229mm | 1255mm |
| Headtube length | 95mm | 105mm | 120mm | 140mm |
| Reach | 425mm | 450mm | 474mm | 500mm |
| Stack | 604mm | 613mm | 627mm | 646mm |
The Full Scoop on the Orbea Rise LT M10
*Components subject to manufacturer changes
Description
The Orbea Rise LT just might be one of the best eMTB's we've come across. The Rise stands out with an incredible build, value, power all in one of the lightest eMTB's available!  We've become huge fans of the Orbea Rise LT as it's one of the most nimble electric mountain bikes we've ridden.Â
*Components subject to manufacturer changes
Motor System
| Motor | Shimano EP801 |
| Battery | Orbea Internal 420Wh / 630Wh |
| Display/Remote | EN600-L |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
Components
| Frame | Orbea Rise OMR 2025, 140mm travel, 29" wheels, Concentric Boost 12x148 |
| Fork | Fox 36 Float Factory 160 Grip X QR15x110 Kashima |
| Rear Shock | Fox Float X Factory 2-Pos Adjust Evol LV Kashima custom tune 210x55mm |
| Front Brake | Shimano XT M8120 Hydraulic Disc |
| Rear Brake | Shimano XT M8120 Hydraulic Disc |
| Rear Derailleur | Shimano XT M8100 SGS Shadow Plus |
| Shift Levers | Shimano SLX M7100 I-Spec EV |
| Chain | Shimano M7100 |
| Cassette | Shimano CS-M7100 10-51t 12-Speed |
| Crankset | Shimano Steps EM600 |
| Chain Ring | Spec not provided |
| Chain Guard | Orbea Rise chainguide |
| Rims | Oquo Mountain Control MC32TEAM, alloy hookless rim, DT350 6IS hub, 32mm internal width, Sapim D-Sprint / Race spokes, 29" |
| Front Hub | Spec not provided |
| Rear Hub | Spec not provided |
| Front Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Rear Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Handlebar | OC Mountain Control MC10 Carbon, Rise 20, Width 800 |
| Stem | OC Mountain Control MC20, 0º |
| Headset | Alloy 1-1/2", Black Oxidated Bearing |
| Grips | Ergon GE10 |
| Saddle | Fizik Terra Ridon X5 145mm |
| Seatpost | OC MC21 Mountain Control Dropper, 31.6mm |
Extras
| Pedals | Not applicable |
| Front Light | Not applicable |
| Rear Light | Not applicable |
| Kickstand | Not applicable |
| Rear Carrier | Not applicable |
| Fenders | Not applicable |
| Bell | Not applicable |
| Lock | Not applicable |
| Mirror | Not applicable |
Geometry
| FRAME SIZE | S | M | L | XL |
|---|---|---|---|---|
| Seattube length | 380mm | 420mm | 450mm | 490mm |
| Toptube length | 605mm | 625mm | 650mm | 670mm |
| Bottom bracket drop | -25mm | -25mm | -25mm | -25mm |
| Bottom bracket height | 350mm | 350mm | 350mm | 350mm |
| Chainstay length | 455mm | 455mm | 455mm | 455mm |
| Seat tube angle | 73.5° | 73.5° | 73.5° | 73.5° |
| Effective seattube angle | 77° | 77° | 77° | 77° |
| Headtube angle | 66° | 66° | 66° | 66° |
| Fork Offset | mm | mm | mm | mm |
| Wheelbase | 1180mm | 1205mm | 1229mm | 1255mm |
| Headtube length | 95mm | 105mm | 120mm | 140mm |
| Reach | 425mm | 450mm | 474mm | 500mm |
| Stack | 604mm | 613mm | 627mm | 646mm |
