The Full Scoop on the Orbea Rise LT M-Team
The Orbea Rise M-TEAM is an ebike designed specifically for the trail rider; it is minimalist, integrated and sleek with no bulky components to take you out of the moment, bringing you closer to the trails and the ride. Orbea Rise M-TEAM rules the zone between long-travel enduro territory and skinny-tire XC efficiency that most of us encounter every day. Orbea Rise M-TEAM's Shimano EP8 motor and and customizable RS power profiles delivers a highly responsive and super-efficient system. It’s an amazingly natural feeling that encourages you to pedal. The Orbea Rise M-TEAM offers top of the line, performance bike spec for the most aggressive riders. Orbea Rise M-TEAM is capable of handling the widest variety of terrain without making big compromises in any aspect of performance.
Components subject to manufacturer changesÂ
| Motor | Shimano EP801 |
| Battery | Orbea Internal 420Wh / 630Wh |
| Display/Remote | EN600-L |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
| Frame | Orbea Rise OMR 2025, 140mm travel, 29" wheels, Concentric Boost 12x148 |
| Fork | Fox 36 Float Factory 160 Grip X QR15x110 Kashima |
| Rear Shock | Fox DHX Factory 2-Pos Adjust custom tune 210x55mm |
| Front Brake | Shimano XTR M9120Hydraulic Disc |
| Rear Brake | Shimano XTR M9120Hydraulic Disc |
| Rear Derailleur | Shimano XT Di2 M8150 12s SGS Shadow Plus |
| Shift Levers | Shimano M8150 |
| Chain | Shimano CN-9100 |
| Cassette | Shimano XTR M9100 10-51t 12-Speed |
| Crankset | Shimano Steps EM900 |
| Chain Ring | Spec not provided |
| Chain Guard | Orbea Rise chainguide |
| Rims | Oquo Mountain Control MC32LTD, carbon hookless rim, DT350 6IS hub, 32mm internal width, Sapim D-Sprint / Race spokes, 29" |
| Front Hub | Spec not provided |
| Rear Hub | Spec not provided |
| Front Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Rear Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Handlebar | OC Mountain Control MC10 Carbon, Rise 20, Width 800 |
| Stem | OC Mountain Control MC11 Alu SL, 0º |
| Headset | Alloy 1-1/2", Black Oxidated Bearing |
| Grips | Ergon GE10 |
| Saddle | Fizik Terra Ridon X1 145mm |
| Seatpost | Fox Transfer Factory Kashima Dropper 31.6 |
| Pedals | Not applicable |
| Front Light | Not applicable |
| Rear Light | Not applicable |
| Kickstand | Not applicable |
| Rear Carrier | Not applicable |
| Fenders | Not applicable |
| Bell | Not applicable |
| Lock | Not applicable |
| Mirror | Not applicable |
| FRAME SIZE | S | M | L | XL |
|---|---|---|---|---|
| Seattube length | 380mm | 420mm | 450mm | 490mm |
| Toptube length | 605mm | 625mm | 650mm | 670mm |
| Bottom bracket drop | -25mm | -25mm | -25mm | -25mm |
| Bottom bracket height | 350mm | 350mm | 350mm | 350mm |
| Chainstay length | 455mm | 455mm | 455mm | 455mm |
| Seat tube angle | 73.5° | 73.5° | 73.5° | 73.5° |
| Effective seattube angle | 77° | 77° | 77° | 77° |
| Headtube angle | 66° | 66° | 66° | 66° |
| Fork Offset | mm | mm | mm | mm |
| Wheelbase | 1180mm | 1205mm | 1229mm | 1255mm |
| Headtube length | 95mm | 105mm | 120mm | 140mm |
| Reach | 425mm | 450mm | 474mm | 500mm |
| Stack | 604mm | 613mm | 627mm | 646mm |
The Full Scoop on the Orbea Rise LT M-Team
Description
The Orbea Rise M-TEAM is an ebike designed specifically for the trail rider; it is minimalist, integrated and sleek with no bulky components to take you out of the moment, bringing you closer to the trails and the ride. Orbea Rise M-TEAM rules the zone between long-travel enduro territory and skinny-tire XC efficiency that most of us encounter every day. Orbea Rise M-TEAM's Shimano EP8 motor and and customizable RS power profiles delivers a highly responsive and super-efficient system. It’s an amazingly natural feeling that encourages you to pedal. The Orbea Rise M-TEAM offers top of the line, performance bike spec for the most aggressive riders. Orbea Rise M-TEAM is capable of handling the widest variety of terrain without making big compromises in any aspect of performance.
Components subject to manufacturer changesÂ
Motor System
| Motor | Shimano EP801 |
| Battery | Orbea Internal 420Wh / 630Wh |
| Display/Remote | EN600-L |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
Components
| Frame | Orbea Rise OMR 2025, 140mm travel, 29" wheels, Concentric Boost 12x148 |
| Fork | Fox 36 Float Factory 160 Grip X QR15x110 Kashima |
| Rear Shock | Fox DHX Factory 2-Pos Adjust custom tune 210x55mm |
| Front Brake | Shimano XTR M9120Hydraulic Disc |
| Rear Brake | Shimano XTR M9120Hydraulic Disc |
| Rear Derailleur | Shimano XT Di2 M8150 12s SGS Shadow Plus |
| Shift Levers | Shimano M8150 |
| Chain | Shimano CN-9100 |
| Cassette | Shimano XTR M9100 10-51t 12-Speed |
| Crankset | Shimano Steps EM900 |
| Chain Ring | Spec not provided |
| Chain Guard | Orbea Rise chainguide |
| Rims | Oquo Mountain Control MC32LTD, carbon hookless rim, DT350 6IS hub, 32mm internal width, Sapim D-Sprint / Race spokes, 29" |
| Front Hub | Spec not provided |
| Rear Hub | Spec not provided |
| Front Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Rear Tire | Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip |
| Handlebar | OC Mountain Control MC10 Carbon, Rise 20, Width 800 |
| Stem | OC Mountain Control MC11 Alu SL, 0º |
| Headset | Alloy 1-1/2", Black Oxidated Bearing |
| Grips | Ergon GE10 |
| Saddle | Fizik Terra Ridon X1 145mm |
| Seatpost | Fox Transfer Factory Kashima Dropper 31.6 |
Extras
| Pedals | Not applicable |
| Front Light | Not applicable |
| Rear Light | Not applicable |
| Kickstand | Not applicable |
| Rear Carrier | Not applicable |
| Fenders | Not applicable |
| Bell | Not applicable |
| Lock | Not applicable |
| Mirror | Not applicable |
Geometry
| FRAME SIZE | S | M | L | XL |
|---|---|---|---|---|
| Seattube length | 380mm | 420mm | 450mm | 490mm |
| Toptube length | 605mm | 625mm | 650mm | 670mm |
| Bottom bracket drop | -25mm | -25mm | -25mm | -25mm |
| Bottom bracket height | 350mm | 350mm | 350mm | 350mm |
| Chainstay length | 455mm | 455mm | 455mm | 455mm |
| Seat tube angle | 73.5° | 73.5° | 73.5° | 73.5° |
| Effective seattube angle | 77° | 77° | 77° | 77° |
| Headtube angle | 66° | 66° | 66° | 66° |
| Fork Offset | mm | mm | mm | mm |
| Wheelbase | 1180mm | 1205mm | 1229mm | 1255mm |
| Headtube length | 95mm | 105mm | 120mm | 140mm |
| Reach | 425mm | 450mm | 474mm | 500mm |
| Stack | 604mm | 613mm | 627mm | 646mm |
