Orbea Rise SL M20
Orbea Rise SL M20
Couldn't load pickup availability
The Full Scoop on the Orbea Rise SL M20
The Orbea Rise SL M20 is an ebike designed specifically for the trail rider; it is minimalist, integrated and sleek with no bulky components to take you out of the moment, bringing you closer to the trails and the ride. Orbea Rise SL M20 rules the zone between long-travel enduro territory and skinny-tire XC efficiency that most of us encounter every day. Orbea Rise SL M20's Shimano EP600 motor and and customizable RS power profiles delivers a highly responsive and super-efficient system. It’s an amazingly natural feeling that encourages you to pedal. Orbea Rise SL M20 is capable of handling the widest variety of terrain without making big compromises in any aspect of performance.
*Components subject to manufacturer changesÂ
| Motor | Shimano EP600 |
| Battery | Orbea Internal 420Wh / 630Wh |
| Display/Remote | EN600-L |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
| Frame | Orbea Rise OMR 2025, 140mm travel, 29" wheels, Concentric Boost 12x148 |
| Fork | Fox 34 Float Performance 140 Grip 3-Pos QR15x110 |
| Rear Shock | Fox Float Performance 2-Pos Evol LV custom tune 210x50mm |
| Front Brake | Shimano M6100 Hydraulic Disc |
| Rear Brake | Shimano M6100 Hydraulic Disc |
| Rear Derailleur | Shimano SLX M7100 SGS Shadow Plus |
| Shift Levers | Shimano SLX M7100 I-Spec EV |
| Chain | Shimano M6100 |
| Cassette | Shimano CS-M7100 10-51t 12-Speed |
| Crankset | Shimano Steps EM600 |
| Chain Ring | Spec not provided |
| Chain Guard | Orbea Rise chainguide |
| Rims | Race Face AR 30c Tubeless ready |
| Front Hub | Spec not provided |
| Rear Hub | Spec not provided |
| Front Tire | Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Soft Compound, Addix, Brown |
| Rear Tire | Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Soft Compound, Addix, Brown |
| Handlebar | OC Mountain Control MC31, Rise20, Width 800 |
| Stem | OC Mountain Control MC20, 0º |
| Headset | Alloy 1-1/2", Black Oxidated Bearing |
| Grips | OC Lock On |
| Saddle | Fizik Terra Ridon X5 145mm |
| Seatpost | OC MC21 Mountain Control Dropper, 31.6mm |
| Pedals | Not applicable |
| Front Light | Not applicable |
| Rear Light | Not applicable |
| Kickstand | Not applicable |
| Rear Carrier | Not applicable |
| Fenders | Not applicable |
| Bell | Not applicable |
| Lock | Not applicable |
| Mirror | Not applicable |
| FRAME SIZE | S | M | L | XL |
|---|---|---|---|---|
| Seattube length | 380mm | 420mm | 450mm | 490mm |
| Toptube length | 605mm | 625mm | 650mm | 670mm |
| Bottom bracket drop | -25mm | -25mm | -25mm | -25mm |
| Bottom bracket height | 350mm | 350mm | 350mm | 350mm |
| Chainstay length | 455mm | 455mm | 455mm | 455mm |
| Seat tube angle | 73.5° | 73.5° | 73.5° | 73.5° |
| Effective seattube angle | 77° | 77° | 77° | 77° |
| Headtube angle | 66° | 66° | 66° | 66° |
| Fork Offset | mm | mm | mm | mm |
| Wheelbase | 1180mm | 1205mm | 1229mm | 1255mm |
| Headtube length | 95mm | 105mm | 120mm | 140mm |
| Reach | 425mm | 450mm | 474mm | 500mm |
| Stack | 604mm | 613mm | 627mm | 646mm |
The Full Scoop on the Orbea Rise SL M20
Description
The Orbea Rise SL M20 is an ebike designed specifically for the trail rider; it is minimalist, integrated and sleek with no bulky components to take you out of the moment, bringing you closer to the trails and the ride. Orbea Rise SL M20 rules the zone between long-travel enduro territory and skinny-tire XC efficiency that most of us encounter every day. Orbea Rise SL M20's Shimano EP600 motor and and customizable RS power profiles delivers a highly responsive and super-efficient system. It’s an amazingly natural feeling that encourages you to pedal. Orbea Rise SL M20 is capable of handling the widest variety of terrain without making big compromises in any aspect of performance.
*Components subject to manufacturer changesÂ
Motor System
| Motor | Shimano EP600 |
| Battery | Orbea Internal 420Wh / 630Wh |
| Display/Remote | EN600-L |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
Components
| Frame | Orbea Rise OMR 2025, 140mm travel, 29" wheels, Concentric Boost 12x148 |
| Fork | Fox 34 Float Performance 140 Grip 3-Pos QR15x110 |
| Rear Shock | Fox Float Performance 2-Pos Evol LV custom tune 210x50mm |
| Front Brake | Shimano M6100 Hydraulic Disc |
| Rear Brake | Shimano M6100 Hydraulic Disc |
| Rear Derailleur | Shimano SLX M7100 SGS Shadow Plus |
| Shift Levers | Shimano SLX M7100 I-Spec EV |
| Chain | Shimano M6100 |
| Cassette | Shimano CS-M7100 10-51t 12-Speed |
| Crankset | Shimano Steps EM600 |
| Chain Ring | Spec not provided |
| Chain Guard | Orbea Rise chainguide |
| Rims | Race Face AR 30c Tubeless ready |
| Front Hub | Spec not provided |
| Rear Hub | Spec not provided |
| Front Tire | Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Soft Compound, Addix, Brown |
| Rear Tire | Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Soft Compound, Addix, Brown |
| Handlebar | OC Mountain Control MC31, Rise20, Width 800 |
| Stem | OC Mountain Control MC20, 0º |
| Headset | Alloy 1-1/2", Black Oxidated Bearing |
| Grips | OC Lock On |
| Saddle | Fizik Terra Ridon X5 145mm |
| Seatpost | OC MC21 Mountain Control Dropper, 31.6mm |
Extras
| Pedals | Not applicable |
| Front Light | Not applicable |
| Rear Light | Not applicable |
| Kickstand | Not applicable |
| Rear Carrier | Not applicable |
| Fenders | Not applicable |
| Bell | Not applicable |
| Lock | Not applicable |
| Mirror | Not applicable |
Geometry
| FRAME SIZE | S | M | L | XL |
|---|---|---|---|---|
| Seattube length | 380mm | 420mm | 450mm | 490mm |
| Toptube length | 605mm | 625mm | 650mm | 670mm |
| Bottom bracket drop | -25mm | -25mm | -25mm | -25mm |
| Bottom bracket height | 350mm | 350mm | 350mm | 350mm |
| Chainstay length | 455mm | 455mm | 455mm | 455mm |
| Seat tube angle | 73.5° | 73.5° | 73.5° | 73.5° |
| Effective seattube angle | 77° | 77° | 77° | 77° |
| Headtube angle | 66° | 66° | 66° | 66° |
| Fork Offset | mm | mm | mm | mm |
| Wheelbase | 1180mm | 1205mm | 1229mm | 1255mm |
| Headtube length | 95mm | 105mm | 120mm | 140mm |
| Reach | 425mm | 450mm | 474mm | 500mm |
| Stack | 604mm | 613mm | 627mm | 646mm |
