The Full Scoop on the Orbea Wild LT M20
The M20 is the entry point to the Wild LT carbon platform — same OMR frame, same DJI Avinox M2S motor, same 170mm Concentric Boost suspension geometry as every other carbon Wild LT. What changes is the spec sheet around it: RockShox ZEB Base fork, Fox Float X Performance shock, Shimano Deore drivetrain, and Race Face AR alloy wheels.
These aren't downgrades that change how the bike rides — Shimano Deore is the most reliable 12-speed groupset in mountain biking, and the ZEB Base/Float X Performance combo handles 170mm duties with proven composure. Galfer Wave 200mm rotors give the Shimano MT420 brakes plenty to work with.
For under $8,000, the M20 puts you on a carbon full-power e-MTB with Orbea's latest geometry, the Avinox M2S motor, and an 800Wh battery. The frame is the ride — and the frame is identical to every other Wild LT in the lineup.
| Motor | DJI Avinox M2S |
| Torque | 130 Nm standard / 150 Nm Superboost |
| Battery | DJI Avinox 800Wh integrated |
| Display | DJI Avinox DP100 |
| Charger | DJI Avinox 4A |
| Remote | DJI Avinox BC100 |
| Classification | Class 1 (20 mph pedal assist) |
| Frame | Orbea Wild OMR 2027 Carbon, 29" wheels, Concentric Boost 12x148 |
| Fork | RockShox ZEB Base DebonAir+ 170, E-MTB Specific, QR15x110 Boost |
| Rear Shock | Fox Float X Performance Trunnion 2-Pos Evol LV, 205x65mm |
| Headset | Acros ZS56 |
| Shifter | Shimano Deore M6200 I-Spec EV |
| Rear Derailleur | Shimano Deore M7200 SGS Shadow Plus |
| Cassette | Shimano CS-M6200, 10-51T, 12-Speed |
| Chain | Shimano M6100 |
| Crankset | e*thirteen Helix Core e*spec, 34T |
| Brakes | Shimano MT420 Hydraulic Disc |
| Rotors | Galfer Wave, 200mm front / 200mm rear |
| Wheels | Race Face AR 30c Tubeless Ready |
| Front Tire | Maxxis Assegai 2.50" 60TPI 3C MaxxGrip EXO+ TR |
| Rear Tire | Maxxis Minion 2.40" 120x2TPI 3C MaxxTerra DD TR |
| Handlebar | OC Mountain Control MC30, Rise 20, Width 800mm |
| Stem | OC Mountain Control MC21, 0° |
| Dropper Post | OC Mountain Control MC22, 31.6mm, Dropper |
| Dropper Lever | Shimano SL-MT500 I-Spec EV |
| Saddle | Fizik Aidon, 208x145mm, manganese rails |
| Computer Mount | OC CM-05, Garmin/Sigma |
| Chainguide | Orbea eBike chainguide |
| Grips | OC Lock On |
| Pedals | Not included |
