Orbea Wild LT M20 Mullet 20mph
Orbea Wild LT M20 Mullet 20mph
The Full Scoop on the Orbea Wild LT M20 Mullet
The most accessible carbon Wild LT, in the mullet configuration that favors playful handling in steep terrain. Same OMR carbon frame and DJI Avinox M2S motor as the rest of the lineup, same 170mm of Concentric Boost suspension travel, with a 29/27.5 wheel setup that quickens the rear end and lowers the center of gravity.
RockShox ZEB Base handles the front end with 170mm of DebonAir+ travel. Fox Float X Performance manages the rear. Shimano Deore runs clean through a 10-51T cassette. Race Face AR alloy wheels in the mixed-wheel configuration, Maxxis Assegai/Minion tires, and Shimano MT420 brakes with 200mm Galfer rotors.
The M20 Mullet is the argument that you don't need to spend five figures to ride a carbon e-MTB that handles like it was designed by people who actually ride steep trails. Because it was.
| Motor | DJI Avinox M2S |
| Torque | 130 Nm standard / 150 Nm Superboost |
| Battery | DJI Avinox 800Wh integrated |
| Display | DJI Avinox DP100 |
| Charger | DJI Avinox 4A |
| Remote | DJI Avinox BC100 |
| Classification | Class 1 (20 mph pedal assist) |
| Frame | Orbea Wild OMR 2027 Carbon, Mullet, Concentric Boost 12x148 |
| Fork | RockShox ZEB Base DebonAir+ 170, E-MTB Specific, QR15x110 Boost |
| Rear Shock | Fox Float X Performance Trunnion 2-Pos Evol LV, 205x65mm |
| Headset | Acros ZS56 |
| Shifter | Shimano Deore M6200 I-Spec EV |
| Rear Derailleur | Shimano Deore M7200 SGS Shadow Plus |
| Cassette | Shimano CS-M6200, 10-51T, 12-Speed |
| Chain | Shimano M6100 |
| Crankset | e*thirteen Helix Core e*spec, 34T |
| Brakes | Shimano MT420 Hydraulic Disc |
| Rotors | Galfer Wave, 200mm front / 200mm rear |
| Wheels | Race Face AR 30c Tubeless Ready (29" front / 27.5" rear) |
| Front Tire | Maxxis Assegai 2.50" 60TPI 3C MaxxGrip EXO+ TR |
| Rear Tire | Maxxis Minion 2.40" 120x2TPI 3C MaxxTerra DD TR |
| Handlebar | OC Mountain Control MC30, Rise 20, Width 800mm |
| Stem | OC Mountain Control MC21, 0° |
| Dropper Post | OC Mountain Control MC22, 31.6mm, Dropper |
| Dropper Lever | Shimano SL-MT500 I-Spec EV |
| Saddle | Fizik Aidon, 208x145mm, manganese rails |
| Computer Mount | OC CM-05, Garmin/Sigma |
| Chainguide | Orbea eBike chainguide |
| Grips | OC Lock On |
| Pedals | Not included |
The Full Scoop on the Orbea Wild LT M20 Mullet
The most accessible carbon Wild LT, in the mullet configuration that favors playful handling in steep terrain. Same OMR carbon frame and DJI Avinox M2S motor as the rest of the lineup, same 170mm of Concentric Boost suspension travel, with a 29/27.5 wheel setup that quickens the rear end and lowers the center of gravity.
RockShox ZEB Base handles the front end with 170mm of DebonAir+ travel. Fox Float X Performance manages the rear. Shimano Deore runs clean through a 10-51T cassette. Race Face AR alloy wheels in the mixed-wheel configuration, Maxxis Assegai/Minion tires, and Shimano MT420 brakes with 200mm Galfer rotors.
The M20 Mullet is the argument that you don't need to spend five figures to ride a carbon e-MTB that handles like it was designed by people who actually ride steep trails. Because it was.
Motor System
| Motor | DJI Avinox M2S |
| Torque | 130 Nm standard / 150 Nm Superboost |
| Battery | DJI Avinox 800Wh integrated |
| Display | DJI Avinox DP100 |
| Charger | DJI Avinox 4A |
| Remote | DJI Avinox BC100 |
| Classification | Class 1 (20 mph pedal assist) |
Components
| Frame | Orbea Wild OMR 2027 Carbon, Mullet, Concentric Boost 12x148 |
| Fork | RockShox ZEB Base DebonAir+ 170, E-MTB Specific, QR15x110 Boost |
| Rear Shock | Fox Float X Performance Trunnion 2-Pos Evol LV, 205x65mm |
| Headset | Acros ZS56 |
| Shifter | Shimano Deore M6200 I-Spec EV |
| Rear Derailleur | Shimano Deore M7200 SGS Shadow Plus |
| Cassette | Shimano CS-M6200, 10-51T, 12-Speed |
| Chain | Shimano M6100 |
| Crankset | e*thirteen Helix Core e*spec, 34T |
| Brakes | Shimano MT420 Hydraulic Disc |
| Rotors | Galfer Wave, 200mm front / 200mm rear |
| Wheels | Race Face AR 30c Tubeless Ready (29" front / 27.5" rear) |
| Front Tire | Maxxis Assegai 2.50" 60TPI 3C MaxxGrip EXO+ TR |
| Rear Tire | Maxxis Minion 2.40" 120x2TPI 3C MaxxTerra DD TR |
Extras
| Handlebar | OC Mountain Control MC30, Rise 20, Width 800mm |
| Stem | OC Mountain Control MC21, 0° |
| Dropper Post | OC Mountain Control MC22, 31.6mm, Dropper |
| Dropper Lever | Shimano SL-MT500 I-Spec EV |
| Saddle | Fizik Aidon, 208x145mm, manganese rails |
| Computer Mount | OC CM-05, Garmin/Sigma |
| Chainguide | Orbea eBike chainguide |
| Grips | OC Lock On |
| Pedals | Not included |
