Riese & Muller Nevo4 GT Touring HS
Riese & Muller Nevo4 GT Touring HS
Regular price
$6,599.00
Sale price
$6,599.00
Regular price
Unit price
per
- PLEASE NOTE: Riese & Muller bikes can be purchased locally from Fly Rides at our San Diego/Poway store.
- We are also happy to ship these bikes to addresses that are at least 100 miles away from another Riese & Muller dealer.
- Call or text us at (619) 344-0211 to build your dream bike and discuss deliverability!
The Full Scoop on the Riese & Muller Nevo4 GT Touring HS
-
-
Motor Performance Line Speed (Gen4)
Battery Bosch PowerPack 500 Performance, 36 V, 13,4 Ah/500Wh*; Bosch PowerTube 500 Horizontal, 36 V, 13,4 Ah/500Wh*; Bosch PowerTube 625 Horizontal, 36 V, 13,4 Ah/625Wh*
Display Bosch Intuvia; Bosch Nyon*; Bosch Kiox* Smartphone hub*
Charger Spec not provided -
Frame Spec not provided Fork Suntour Aion, Air, tapered, 100mm; Suntour XCR32 27,5", Air, tapered, black*
Rear Shock Not applicable Front Brake Magura MT4, disc brake; Magura MT5, disc brake
Rear Brake Magura MT4, disc brake; Magura MT5, disc brake
Rear Derailleur Shimano Deore XT Shadow+, 11-speed
Shift Levers Shimano SLX, 11-speed; Shimano Deore, 11-speed Chain KMC X11 ( 123x ); KMC X11 ( 121x )* Cassette Shimano Deore 10-S 11-43 Linkglide Crankset FSA/Riese & Müller, 170 mm
Chain Ring 42T; 48T* Chain Guard Chain guard ring Rims Rodi Tryp35 27,5"; Mach1 650, 26"* Front Hub Novatec Disc 32H
Rear Hub Shimano Deore Disc, 36H Front Tire Schwalbe Super Moto-X 62-584 Reflex; Schwalbe Big Ben Plus 55-559 Reflex*; Schwalbe Johnny Watts 60-584*; Schwalbe Smart Sam Plus 57-559 Reflex*
Rear Tire Schwalbe Super Moto-X 62-584 Reflex; Schwalbe Big Ben Plus 55-559 Reflex*; Schwalbe Johnny Watts 60-584*; Schwalbe Smart Sam Plus 57-559 Reflex*
Handlebar Humpert ergotec Ergo XXL, 31,8 mm; Humpert ergotec Trekking, 31,8 mm, Alu*; Satori R&M Custom Komfort, 25,4 mm, Alu*; Satori R&M Custom, 25,4mm, Alu*
Stem Humpert ergotec Barracuda Evo, 90 mm, 20°; Satori R&M Custom, cable integration, adjustable angle, Alu*
Headset Acros IntegrationX, block lock Grips Ergon ergonomic Saddle Selle Royal New Lookin Evo R&M; Selle Royal New Lookin Female Evo R&M*; Selle Royal Nuvola*
Seatpost Cane Creek New Thudbuster ST -
Pedals VP R&M Custom; VP-658, oversized spindle * Front Light Supernova M99 Mini Pro-45
Rear Light Supernova M99, integrated plate illumination and brake light; Supernova M99, integrated brake light* Kickstand Ursus R78 King 2 Kickstand
Rear Carrier Riese & Müller, MIK
Fenders SKS A69R Bell Supernova horn Lock ABUS Shield; ABUS Shield X+* -
43 47 51 56 Height 5'1" - 5'7"
5'5" - 5'10"
5'7" - 6'0"
5'10" - 6'4"
Top tube length [cm]
56
60
62
64
Reach [cm]
34,5
37
39
41
Stack [cm]
64,5
69,5
69,5
69,5
Head tube angle [°] 68,5
68
68,5
68,5
Seat tube angle [°]
74 74
74
74 Trail [mm]
87
96 93
93
Wheelbase [cm]
107
114,5
115,5
117,5
Bottom bracket height [cm]
27,5
27,5 27,5 27,5 Stand-over height [cm]
43,5
43,5
43,5
43,5
Chainstay length [cm]
45
48 48
48
Overall length [cm]
174
185,5
186,5 188,5
Wheel size ['']
26
27,5
27,5
27,5
Head tube length [mm]
170 170 170
170 Front suspension travel [mm] 80
100 100 100 Rear dropout width [mm] 135 135 135
135
Gear ratio [m] 2,16-9,03
2,29-9,56
2,29-9,56
2,29-9,56
Weight [kg] 28,1 28,2 28,3 28,4 Weight [lbs] 62
62
62
63 Gross vehicle weight rating [kg] 140 140 140 140 Weight rating: Luggage rack [kg] 20 27,5 27,5 27,5 Weight rating: Handlebar bag/basket [kg] 5 5 5 5 Childseat compatibility Yes Yes Yes Yes Trailer compatibility: Single wheel/single attachment point Yes Yes Yes Yes Trailer compatibility: Two wheel/single attachment point Yes Yes Yes Yes Compatibility: Tagalong trailer bike Yes Yes Yes Yes
