Scott Contessa Active eRide 930

The Full Scoop on the Scott Contessa Active eRide 930

• Description
• Motor System
• Components
• Extras
• Geometry

• The SCOTT Contessa Active eRIDE 930 features proven electric assist technology in a comfortable off-road package. Now with a new low step frame combined with women's specific contact points, and powered by a 625wh Bosch drive system, the Contessa Active eRIDE will give you hours of trail riding energy. Rack and fender available.

• Motor	Bosch Active Line Plus EU: 25kmh / INT: 20mph
  Battery	PowerTube 500Wh
  Display	Bosch Purion
  Charger	2A Charger

• Frame	Alloy Frame, Integrated cable
  Fork	SR Suntour XCM34 Coil 15x110mm QR axle / Tapered Steerer Remote Lockout / 120mm travel
  Rear Shock	Not applicable
  Front Brake	Shimano BR-MT200 Disc / SM-RT30 CL 180mm
  Rear Brake	Shimano BR-MT200 Disc / RT-EM300 CL 180mm
  Rear Derailleur	Shimano RD-M3100 / 9 Speed
  Shift Levers	Shimano SL-M2000
  Chain	KMC e9S
  Cassette	Shimano CS-HG200-9 ACERA 11-36
  Crankset	FSA CK-220 / 165mm
  Chain Ring	FSA WB437 32T w/CG
  Chain Guard	Spec not provided
  Rims	Syncros X18 / 32H / 30mm / Pin Joint
  Front Hub	Shimano HB-MT400-B CL / 15x110mm
  Rear Hub	Shimano FH-MT400-B CL / Boost 12x148mm
  Front Tire	Kenda Booster 29x2.6" / 30TPI
  Rear Tire	Kenda Booster 29x2.6" / 30TPI
  Handlebar	Syncros 3.0 720mm / 31.8mm / 9° / 12mm rise Syncros Comfort lock-on grips
  Stem	Syncros 3.0 / 7° / Black
  Headset	Syncros OE / Tapered 1.5"-1 1/8" semi integ. OD 50/62mm / ID 44/56mm
  Grips	Spec not provided
  Saddle	Syncros Savona 2.5 V-Concept
  Seatpost	Syncros 3.0 / 31.6mm

• Pedals	Not applicable
  Front Light	Not applicable
  Rear Light	Not applicable
  Kickstand	Not applicable
  Rear Carrier	Not applicable
  Fenders	Not applicable
  Bell	Not applicable
  Lock	Not applicable
  Mirror	Not applicable

• 		XS	S	M	L
  HEAD TUBE ANGLE	A	67 °	67 °	67°	67 °
  HEAD TUBE LENGTH	B	4.3 IN	4.3 IN	4.7 IN	5.1 IN
  TOP TUBE HORIZONTAL	C	22.8 IN	22.8 IN	23.6 IN	24.4 IN
  STANDOVER HEIGHT	D	29.2 IN	30.2 IN	30.4 IN	31.5 IN
  BB OFFSET	E	-2.2 IN	-2.2 IN	-2.2 IN	-2.2 IN
  BB HEIGHT	F	12.6 IN	12.6 IN	12.6 IN	12.6 IN
  WHEEL BASE	G	45.9 IN	45.9 IN	46.7 IN	47.3 IN
  BB CENTER TO TOPTUBE CENTER	H	-	-	-	-
  BB CENTER TO TOP OF SEATTUBE	I	14 IN	15.7 IN	17.3 IN	18.9 IN
  SEAT ANGLE	J	74 °	74 °	74 °	74 °
  CHAINSTAY	K	18.9 IN	18.9 IN	18.9 IN	18.9 IN
  REACH	L	15.7 IN	15.7 IN	16.4IN	17 IN
  STACK	M	24.9 IN	24.9 IN	25.3 IN	25.7 IN
  TRAIL	O	4.5 IN	4.5 IN	4.5 IN	4.4 IN
