The Full Scoop on the Tern Vektron P5i
The Tern Vektron P5i is a folding e-bike for riders who value silence, simplicity, and zero-hassle commuting. A Gates Carbon Drive belt replaces the traditional chain — no grease, no noise, virtually no maintenance. Paired with a Shimano Nexus 5-speed internal gear hub, you can shift at any speed, even standing still at a light.
Powered by a Bosch Performance Line mid-drive motor with a 400Wh battery, the P5i delivers up to 70 miles of range and folds in 10 seconds. The Gen 4 platform features a reinforced OCL+ frame joint, 3D-forged Physis handlepost, and an adjustable cockpit fitting riders from 4'10" to 6'5".
An ABUS frame lock (keyed-alike with the battery lock), integrated rack, Magura hydraulic disc brakes, and a 10-year frame warranty round out a folding e-bike built to last.
| Motor | Bosch BES2 Performance Line, 300% Assist, 65 Nm Torque, Class 1 (20 mph) |
| Battery | Bosch PowerPack 400 Wh |
| Range | 28–70 miles (45–112 km) |
| Display | Bosch Intuvia |
| Charger | 100-120V, 4A — ~3 hrs to 50%, ~6.5 hrs to full |
| Assist Modes | Eco, Tour+, Sport, Turbo |
| Certified | UL 2849, EN 15194 |
| Frame | Tern Vektron 6061-AL, hydroformed, OCL+ frame joint |
| Fork | Tern Tarsus 6061-AL, hydroformed |
| Drivetrain | Gates Carbon Drive CDC belt, Shimano Nexus 5-speed IGH |
| Gear Range | 34–90 inches (263%) |
| Brakes | Magura MT4 hydraulic disc, 160mm rotors |
| Handlepost | Tern Physis 3D, forged aluminum |
| Stem | Tern Andros, adjustable, tool-free |
| Tires | Schwalbe Big Apple 20×2.15, puncture protection, reflective sidewall |
| Saddle | Tern Porter+ by Velo, PrimeGel |
| Pedals | MKS EZY quick-release |
| Grips | Ergon |
| Frame Lock | ABUS, keyed-alike with battery lock |
| Front Light | Tern Valo Direct, 190 lumens, e-bike powered |
| Rear Light | Herrmans H-Trace, e-bike powered |
| Rack | Atlas V, 8-point mounting, 27 kg (59 lb) capacity |
| Rack Compatibility | KLICKfix, Racktime SNAPIT 2.0, Ortlieb Quick-Lock |
| Fenders | SplashGuard, stainless hardware |
| Kickstand | URSUS, rear-mount |
| Fold System | Magnetix 3.0, stands upright when folded |
The Full Scoop on the Tern Vektron P5i
The Tern Vektron P5i is a folding e-bike for riders who value silence, simplicity, and zero-hassle commuting. A Gates Carbon Drive belt replaces the traditional chain — no grease, no noise, virtually no maintenance. Paired with a Shimano Nexus 5-speed internal gear hub, you can shift at any speed, even standing still at a light.
Powered by a Bosch Performance Line mid-drive motor with a 400Wh battery, the P5i delivers up to 70 miles of range and folds in 10 seconds. The Gen 4 platform features a reinforced OCL+ frame joint, 3D-forged Physis handlepost, and an adjustable cockpit fitting riders from 4'10" to 6'5".
An ABUS frame lock (keyed-alike with the battery lock), integrated rack, Magura hydraulic disc brakes, and a 10-year frame warranty round out a folding e-bike built to last.
Motor System
| Motor | Bosch BES2 Performance Line, 300% Assist, 65 Nm Torque, Class 1 (20 mph) |
| Battery | Bosch PowerPack 400 Wh |
| Range | 28–70 miles (45–112 km) |
| Display | Bosch Intuvia |
| Charger | 100-120V, 4A — ~3 hrs to 50%, ~6.5 hrs to full |
| Assist Modes | Eco, Tour+, Sport, Turbo |
| Certified | UL 2849, EN 15194 |
Components
| Frame | Tern Vektron 6061-AL, hydroformed, OCL+ frame joint |
| Fork | Tern Tarsus 6061-AL, hydroformed |
| Drivetrain | Gates Carbon Drive CDC belt, Shimano Nexus 5-speed IGH |
| Gear Range | 34–90 inches (263%) |
| Brakes | Magura MT4 hydraulic disc, 160mm rotors |
| Handlepost | Tern Physis 3D, forged aluminum |
| Stem | Tern Andros, adjustable, tool-free |
| Tires | Schwalbe Big Apple 20×2.15, puncture protection, reflective sidewall |
| Saddle | Tern Porter+ by Velo, PrimeGel |
| Pedals | MKS EZY quick-release |
| Grips | Ergon |
| Frame Lock | ABUS, keyed-alike with battery lock |
Extras
| Front Light | Tern Valo Direct, 190 lumens, e-bike powered |
| Rear Light | Herrmans H-Trace, e-bike powered |
| Rack | Atlas V, 8-point mounting, 27 kg (59 lb) capacity |
| Rack Compatibility | KLICKfix, Racktime SNAPIT 2.0, Ortlieb Quick-Lock |
| Fenders | SplashGuard, stainless hardware |
| Kickstand | URSUS, rear-mount |
| Fold System | Magnetix 3.0, stands upright when folded |
