Riese and Muller Load5 60 Rohloff
Riese and Muller Load5 60 Rohloff
- PLEASE NOTE: Riese & Muller bikes can be purchased locally from Fly Rides at our San Diego/Poway store.
- We are also happy to ship these bikes to addresses that are at least 100 miles away from another Riese & Muller dealer.
- Call or text us at (619) 344-0211 to build your dream bike and discuss deliverability!
The Full Scoop on the Riese and Muller Load5 60 Rohloff
The Load5 60 delivers outstanding agility and control on any surface – from city streets to gravel paths. Its low centre of gravity, full suspension and powerful drive combine to create a smooth, confident and truly enjoyable ride.
Designed for everyday life and big adventures alike, it handles heavy loads and long distances with ease thanks to the optional DualBattery system and co-sprung luggage carrier. The adaptable 24" loading surface is ready for whatever you need to carry – from children and gear to four-legged companions.
With Riese & Müller Control Technology, the Load5 60 stays stable and responsive even on rough terrain. Optional Bosch eBike ABS or IBS braking ensures maximum safety, while the lightweight frame made from 25% recycled aluminium supports up to 441lbs. Adjustable ergonomics and a standard dropper seatpost guarantee comfort, control and the perfect fit for every ride.
*Components subject to manufacturer changes.
| Motor | Bosch Cargo Line, 25km/h 20mph |
| Battery | Bosch PowerPack Frame 800; Bosch PowerPack Frame 725*; Bosch PowerPack Frame 400Wh* |
| Display | Bosch Purion 200; Bosch Kiox 500* |
| Charger | Bosch 4A |
| Frame | arctic*; coal grey matt*; peanut matt*; tundra grey matt* |
| Fork | Suntour Mobie 34 CGO Boost, 20", 80mm; SR Suntour Mobie 34 L Air CGO Boost, 20", 80mm* |
| Rear Shock | X-Fusion Glyde; SR Suntour Air 165x38 * |
| Front Brake | Tektro TRP C 2.3 disc brake; Magura MT C ABS*; Magura MT5, disc brake* |
| Rear Brake | Tektro TRP C 2.3 disc brake; Magura MT C ABS*; Magura MT5, disc brake* |
| Rear Derailleur / Pinion | 19T, Gates drive belt CDX |
| Shift Levers | Rohloff E14 electronic shifter |
| Chain | Gates drive belt CDX |
| Cassette | Spec not provided |
| Crankset | FSA/Riese & Müller, 165 mm |
| Chain Ring | 55T |
| Chain Guard | Included |
| Rims | Mach1 Trucky30 20"; Mach1 Trucky30 26" |
| Front Hub | Novatec Boost Cargo Disc 32H |
| Rear Hub | Rohloff Speedhub E14, 14-speed, Disc, 36H |
| Front Tire | Schwalbe Big Ben Plus 55-406 Reflex; Schwalbe Big Ben Plus 55-559 Reflex; Schwalbe 20" Smart Sam Cargo 60-406 Reflex*; Schwalbe Smart Sam Cargo 60-559 Reflex* |
| Rear Tire | Schwalbe Big Ben Plus 55-406 Reflex; Schwalbe Big Ben Plus 55-559 Reflex; Schwalbe 20" Smart Sam Cargo 60-406 Reflex*; Schwalbe Smart Sam Cargo 60-559 Reflex* |
| Handlebar | Satori Horizon, 31,8 mm, 9°, B=620 mm |
| Stem | Riese & Müller, adjustable height and angle |
| Headset | Acros AZX-221, block lock; TH No. 9, semi-integrated |
| Grips | Ergon economic |
| Saddle | Ergon SF10 Gel |
| Seatpost | Dropper Post X-Fusion Manic 150/170 |
| Pedals | VP R&M Custom; VP-538* |
| Front Light | Supernova M99 Mini Pro-25 |
| Rear Light | Supernova TL3 Pro, integrated brake light |
| Kickstand | Kickstand Riese & Müller |
| Rear Carrier | Riese & Müller |
| Fenders | SKS A65R; SKS A69R |
| Bell | Billy |
| Lock | ABUS Adaptor Chain 2.0 130 cm; ABUS Shield X+ |
| Mirror | Not applicable |
The Full Scoop on the Riese and Muller Load5 60 Rohloff
Description
The Load5 60 delivers outstanding agility and control on any surface – from city streets to gravel paths. Its low centre of gravity, full suspension and powerful drive combine to create a smooth, confident and truly enjoyable ride.
Designed for everyday life and big adventures alike, it handles heavy loads and long distances with ease thanks to the optional DualBattery system and co-sprung luggage carrier. The adaptable 24" loading surface is ready for whatever you need to carry – from children and gear to four-legged companions.
With Riese & Müller Control Technology, the Load5 60 stays stable and responsive even on rough terrain. Optional Bosch eBike ABS or IBS braking ensures maximum safety, while the lightweight frame made from 25% recycled aluminium supports up to 441lbs. Adjustable ergonomics and a standard dropper seatpost guarantee comfort, control and the perfect fit for every ride.
*Components subject to manufacturer changes.
Motor System
| Motor | Bosch Cargo Line, 25km/h 20mph |
| Battery | Bosch PowerPack Frame 800; Bosch PowerPack Frame 725*; Bosch PowerPack Frame 400Wh* |
| Display | Bosch Purion 200; Bosch Kiox 500* |
| Charger | Bosch 4A |
Components
| Frame | arctic*; coal grey matt*; peanut matt*; tundra grey matt* |
| Fork | Suntour Mobie 34 CGO Boost, 20", 80mm; SR Suntour Mobie 34 L Air CGO Boost, 20", 80mm* |
| Rear Shock | X-Fusion Glyde; SR Suntour Air 165x38 * |
| Front Brake | Tektro TRP C 2.3 disc brake; Magura MT C ABS*; Magura MT5, disc brake* |
| Rear Brake | Tektro TRP C 2.3 disc brake; Magura MT C ABS*; Magura MT5, disc brake* |
| Rear Derailleur / Pinion | 19T, Gates drive belt CDX |
| Shift Levers | Rohloff E14 electronic shifter |
| Chain | Gates drive belt CDX |
| Cassette | Spec not provided |
| Crankset | FSA/Riese & Müller, 165 mm |
| Chain Ring | 55T |
| Chain Guard | Included |
| Rims | Mach1 Trucky30 20"; Mach1 Trucky30 26" |
| Front Hub | Novatec Boost Cargo Disc 32H |
| Rear Hub | Rohloff Speedhub E14, 14-speed, Disc, 36H |
| Front Tire | Schwalbe Big Ben Plus 55-406 Reflex; Schwalbe Big Ben Plus 55-559 Reflex; Schwalbe 20" Smart Sam Cargo 60-406 Reflex*; Schwalbe Smart Sam Cargo 60-559 Reflex* |
| Rear Tire | Schwalbe Big Ben Plus 55-406 Reflex; Schwalbe Big Ben Plus 55-559 Reflex; Schwalbe 20" Smart Sam Cargo 60-406 Reflex*; Schwalbe Smart Sam Cargo 60-559 Reflex* |
| Handlebar | Satori Horizon, 31,8 mm, 9°, B=620 mm |
| Stem | Riese & Müller, adjustable height and angle |
| Headset | Acros AZX-221, block lock; TH No. 9, semi-integrated |
| Grips | Ergon economic |
| Saddle | Ergon SF10 Gel |
| Seatpost | Dropper Post X-Fusion Manic 150/170 |
Extras
| Pedals | VP R&M Custom; VP-538* |
| Front Light | Supernova M99 Mini Pro-25 |
| Rear Light | Supernova TL3 Pro, integrated brake light |
| Kickstand | Kickstand Riese & Müller |
| Rear Carrier | Riese & Müller |
| Fenders | SKS A65R; SKS A69R |
| Bell | Billy |
| Lock | ABUS Adaptor Chain 2.0 130 cm; ABUS Shield X+ |
| Mirror | Not applicable |
Geometry
